Nouveau micro-drone ISR souverain : silencieux, résistant au brouillage, doté d’une caméra thermique 640×480, du tracking de cible et de la navigation autonome sans GPS grâce à la reconnaissance visuelle.
Le Parrot ANAFI UKR est un drone tactique ultra-robuste, conçu pour offrir des performances professionnelles dans des conditions extrêmes. Développé par Parrot, fabricant français reconnu pour ses solutions souveraines et innovantes, ce drone compact allie discrétion, autonomie, puissance et résilience.
Le ANAFI UKR est parfaitement adapté pour les professionnels ayant besoin de :
• Size folded: 245 x 160 x 116 mm (9.6 x 6.3 x 4.6”) • Size unfolded: 350 x 665 x 116 mm (13.8 x 26.2 x 4.6”) • Mass: 959 g (2.11 lb) • Maximum take-off mass (MTOM): 1,450 g / 3.20 lb • Maximum transmission range: - 5G*: range without limits - Wi-Fi*: 5 km / 3.1 mi - MARS Radio*: 15 km / 9.32 mi - LoRa: 20 km / 12.43 mi • Maximum flight time: 38 min at 6 m/s airspeed • Maximum flight distance: 23.1 km (14.35 mi) at 10 m/s airspeed • Maximum horizontal airspeed: 17 m/s • Maximum horizontal groundspeed: 12.6 m/s • Maximum ascent speed: 8 m/s • Maximum descent speed: 8 m/s • Maximum wind resistance: - During flight: 15 m/s - During take-off and landing: 15 m/s • Maximum propeller speed: 8,500 rpm • Sound power level at 1 m (3 ft): 77 dBA • Service ceiling: 5,000 m above MSL (Mean Sea Level) • Operating temperature: -36 °C to +50 °C (-33 °F to +122 °F) • No take-off temperature limitation if battery is maintained between -20 °C and +50 °C (-4 °F to +122 °F) • IP53: rain and dust resistant • No NFZ (No-Fly Zones) limitation • Takes off from / lands in the hand of the operator • Optical navigation for GNSS-denied flight • Indoor flight • MicroSD card slot • Deployment time: < 2 min
• Satellite navigation: GPS, GLONASS, Galileo & BeiDou • Barometer and magnetometer • Front and bottom stereo cameras, and vertical range sensor • 4 x 6-axis IMU (3-axis accelerometers + 3-axis gyroscopes) (Flight IMU: ICM-40609-D)
• Zero data shared without user consent • Manage your data privately between drone and device or share anonymous data on secured European servers • SD card AES-XTS encryption with a 512-bit key • Digitally signed firmware • Compliant with FIPS140-2
• 5G* • Wi-Fi* • MARS**(Radio-jamming resistance through Frequency Hopping) • Encrypted backup LoRa radio • Direct video stream resolution: 1080p at 30 fps • AES 256 encryption: packet and radio level
• 2 sensors: 1/2.4” • Digital zoom: 35x • Electronic shutter speed: 1/25 s to 1/10,000 s • ISO range: 100 - 3,200 • Video resolution: 4K / FHD / HD • Video format: MP4 (H.264 & H.265) • Photo resolutions: - Wide: 21 MP (84° FOV) - Rectilinear: up to 16 MP (up to 75.2° FOV) • Photo formats: JPEG, DNG (Digital NeGative RAW)
• Sensor: FLIR BOSON • Resolution: 640 x 512 px • Temperature range: -40 °C to +250 °C (-40 °F to +482 °F) • Thermal sensitivity: ≤60 mK • Measured IR wavelength range: 8 to 14 micrometers • Video resolution: UHD (2160p) at 8.6 fps • Video format: MP4 (H.264 / H.265) • Photo formats: JPEG
• 3-camera IR/EO stabilized gimbal: - Hybrid: 3-axis - Mechanical: 3-axis - Electronics (EIS): 3-axis • Controllable gimbal tilt range: -90° to +90°
• Size: 136 x 73 x 46 mm (5.4 x 2.9 x 1.8”) • Mass: 344 g / 0.76 lb • Type: High density LiPo (227 Wh/kg) • Capacity: 6,800 mAh • Voltage (nominal): 11.55 V (3 x 3.85 V cells) • Charging port: USB-C • Charges fully in 2 h 30 min with the USB-PD (Power Delivery) charger included in the pack • Maximum charging power: 45 W
• Size folded: 171 x 302 x 77 mm (6.7 x 11.9 x 3.0”) • Size unfolded: 171 x 302 x 215 mm (6.7 x 11.9 x 8.5”) • Mass: 1,764 g (3.89 lb) • Battery capacity: 10,000 mAh • Battery voltage (nominal): 7.2 V • Battery charging duration: 2 h (2 h 30 min with tablet) • Autonomy: 4 h 30 min • Ports: USB-C (tablet), USB-C (charging), USB-A (pairing + accessory interface), Ethernet (Remote Antenna feature), HDMI • IP53: rain and dust resistant • ANAFI UKR is supplied with a Samsung tablet, but is also compatible with an iPad Mini • The system is also available without a tablet
• Flight Planning with waypoints and points of interest • Object recognition & tracking • Cursor On Target • Video streaming & recording • EO and IR cameras settings management • Touch & Fly • System settings and management • Flight logs recording and reviewing
*Version Dependant **By special request
